File mapping for onlinelogs

Jump to Best Answer
  • 1.  File mapping for onlinelogs

    Posted 03-24-2017 03:48:00 PM
    Hi, I'm trying to figue out how i can use file mapping with V2P, to get my redologs mapped to a specific directory. on the vdb i'm converting /mnt/provision/devdb/datafile/DEVDB/onlinelog/o1_mf_3_df7b5wtx_.log The converted database have to have redo logs under /u02/oratada/redo So i'm trying this : target directory = /u02/oradata file mapping for redo /DEVDB/onlinelog => to change with /redo => but this gives un error No path matched the mapping rules you provided: "/DEVDB/onlinelog:/redo" Any idea on how to make it working please Regards, Mouhssine
    #DemoEnvironment


  • 2.  RE: File mapping for onlinelogs
    Best Answer

    Posted 03-30-2017 09:18:00 PM
    Hello Mouhssine,

    Unfortunately, you can not use file mapping to modify the location of redo logs.
    You can only use it to change the location of the controlfile and datafiles listed using the query:
    SQL> select name from v$datafile;  NAME -------------------------------------------------------------------------------- /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/system01.dbf /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/undotbs01.dbf /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/sysaux01.dbf /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/users01.dbf /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/dbv_ZX5G.dbf /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/tts01.dbf

    In order to move the redo logs to /u01/oradata/redo on the physical database, you have to do it after the V2P is complete.

    I did a quick test using V2P
    I set my target directory to /u01/oradata (you would use /u02/oradata)

    After it completed I did an export ORACLE_SID=VtesD5D and connected to my new physical database using "sqlplus / as sysdba"

    I then did the folllowing:

    SQL> select member from v$logfile;
    MEMBER
    --------------------------------------------------------------------------------
    /u01/oradata/TESTC/onlinelog/o1_mf_3_df326wkd_.log
    /u01/oradata/TESTC/onlinelog/o1_mf_2_df326w20_.log
    /u01/oradata/TESTC/onlinelog/o1_mf_1_df326vld_.log
    /u01/oradata/VTESTC_D5D/onlinelog/o1_mf_4_dftx83qg_.log
    /u01/oradata/VTESTC_D5D/onlinelog/o1_mf_5_dftx83w2_.log

    SQL> shutdown
    Database closed.
    Database dismounted.
    ORACLE instance shut down.
    SQL> quit
    Disconnected from Oracle Database 10g Enterprise Edition Release 10.2.0.5.0 - 64bit Production
    With the Partitioning, OLAP, Data Mining and Real Application Testing options

    mkdir /u01/oradata/redo

    mv /u01/oradata/TESTC/onlinelog/o1_mf_3_df326wkd_.log /u01/oradata/redo/
    mv /u01/oradata/TESTC/onlinelog/o1_mf_2_df326w20_.log /u01/oradata/redo/
    mv /u01/oradata/TESTC/onlinelog/o1_mf_1_df326vld_.log /u01/oradata/redo/
    mv /u01/oradata/VTESTC_D5D/onlinelog/o1_mf_4_dftx83qg_.log /u01/oradata/redo/
    mv /u01/oradata/VTESTC_D5D/onlinelog/o1_mf_5_dftx83w2_.log /u01/oradata/redo/

    ls -al /u01/oradata/redo
    total 162520
    drwxrwxr-x  2 ora10205 oinstall     4096 Mar 30 17:35 .
    drwxrwxr-x 11 ora10205 oinstall     4096 Mar 30 17:13 ..
    -rw-rw-r--  1 ora10205 oinstall 52429312 Mar 30 17:14 o1_mf_1_df326vld_.log
    -rw-rw-r--  1 ora10205 oinstall 52429312 Mar 30 17:14 o1_mf_2_df326w20_.log
    -rw-rw-r--  1 ora10205 oinstall 52429312 Mar 30 17:32 o1_mf_3_df326wkd_.log
    -rw-r-----  1 ora10205 oinstall  4194816 Mar 30 17:14 o1_mf_4_dftx83qg_.log
    -rw-r-----  1 ora10205 oinstall  4194816 Mar 30 17:14 o1_mf_5_dftx83w2_.log

    sqlplus / as sysdba
    SQL*Plus: Release 10.2.0.5.0 - Production on Thu Mar 30 17:36:15 2017

    Copyright (c) 1982, 2010, Oracle.  All Rights Reserved.

    Connected to an idle instance.

    SQL> startup mount
    ORACLE instance started.

    Total System Global Area  591396864 bytes
    Fixed Size    2098048 bytes
    Variable Size  163581056 bytes
    Database Buffers  419430400 bytes
    Redo Buffers    6287360 bytes
    Database mounted.

    SQL> alter database rename file '/u01/oradata/TESTC/onlinelog/o1_mf_3_df326wkd_.log' to '/u01/oradata/redo/o1_mf_3_df326wkd_.log';

    Database altered.

    SQL> alter database rename file '/u01/oradata/TESTC/onlinelog/o1_mf_2_df326w20_.log' to '/u01/oradata/redo/o1_mf_2_df326w20_.log';

    Database altered.

    SQL> alter database rename file '/u01/oradata/TESTC/onlinelog/o1_mf_1_df326vld_.log' to '/u01/oradata/redo/o1_mf_1_df326vld_.log';

    Database altered.

    SQL> alter database rename file '/u01/oradata/VTESTC_D5D/onlinelog/o1_mf_4_dftx83qg_.log' to '/u01/oradata/redo/o1_mf_4_dftx83qg_.log';

    Database altered.

    SQL> alter database rename file '/u01/oradata/VTESTC_D5D/onlinelog/o1_mf_5_dftx83w2_.log' to '/u01/oradata/redo/o1_mf_5_dftx83w2_.log';

    Database altered.

    SQL> alter database open;
    Database altered.

    SQL> select member from v$logfile;

    MEMBER
    --------------------------------------------------------------------------------
    /u01/oradata/redo/o1_mf_3_df326wkd_.log
    /u01/oradata/redo/o1_mf_2_df326w20_.log
    /u01/oradata/redo/o1_mf_1_df326vld_.log
    /u01/oradata/redo/o1_mf_4_dftx83qg_.log
    /u01/oradata/redo/o1_mf_5_dftx83w2_.log

    SQL> quit
    Disconnected from Oracle Database 10g Enterprise Edition Release 10.2.0.5.0 - 64bit Production
    With the Partitioning, OLAP, Data Mining and Real Application Testing options


    An additional note:

    When you use File Mapping, keep the following in mind:
    You can only use file mapping to relocate datafiles shown in v$datafile and the controlfile.

    You can see which objects can be relocated by clicking the gree + sign to the right of File Mapping and then selecting "Validate"

    That will provide you with the Original Path and the Result, which will be identical.

    On the Source File Match side everything is relative to the db_create_file_dest parameter value, so you leave that off and just include everything that follows, including a leading /

    On the Replacement side, everything is relative to the Target Directory, so you leave off the Target Directory (/u02/oradata)


    SQL> show parameter db_create_file_dest
    /mnt/provision/testc/datafile

    SQL> select name from v$datafile;
    NAME
    --------------------------------------------------------------------------------
    /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/system01.dbf
    /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/undotbs01.dbf
    /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/sysaux01.dbf
    /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/users01.dbf
    /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/dbv_ZX5G.dbf
    /mnt/provision/testc/datafile/datafile/dbdhcp1/oradata/dbdhcp1/tts01.dbf


    As a test, to verify that I was doing everything correctly, I added "/datafile/dbdhcp1/oradata/dbdhcp1/dbv_ZX5G.dbf" as the Source File Match and set the Replacement to "/u01/oradata/redo/dbv_ZX5G.dbf"  (as I already created on /u01/oradata/redo on the target) and clicked Validate.

    You can see the result below.



    I then checked the target after the V2P completed (but before moving redo) and saw that the file was mapped correctly.

    ls -al /u01/oradata/redototal 162520
    drwxrwxr-x  2 ora10205 oinstall     4096 Mar 30 17:35 .
    drwxrwxr-x 11 ora10205 oinstall     4096 Mar 30 17:13 ..
    -rw-rw-r--  1 ora10205 oinstall   532480 Mar 30 17:57 dbv_ZX5G.dbf

    I confirmed it in sqlplus

    SQL> select name from v$datafile;
    NAME
    --------------------------------------------------------------------------------
    /u01/oradata/datafile/dbdhcp1/oradata/dbdhcp1/system01.dbf
    /u01/oradata/datafile/dbdhcp1/oradata/dbdhcp1/undotbs01.dbf
    /u01/oradata/datafile/dbdhcp1/oradata/dbdhcp1/sysaux01.dbf
    /u01/oradata/datafile/dbdhcp1/oradata/dbdhcp1/users01.dbf
    /u01/oradata/redo/dbv_ZX5G.dbf
    /u01/oradata/datafile/dbdhcp1/oradata/dbdhcp1/tts01.dbf

    Hope this helps.
    Stephanie


  • 3.  RE: File mapping for onlinelogs

    Posted 03-31-2017 07:07:00 AM
    Hi Stephanie, I was suspecting that, thanks for your confirmation. Is it possible to ask for an enhancment request to add redologs mapping as they are part of database datafiles just as controlfiles and datafile. Or at least allow using hooks to automate the redo logs move to the new directorie. Regards, Mouhssine


  • 4.  RE: File mapping for onlinelogs

    Posted 03-31-2017 11:22:00 AM
    Mouhssine,
    Sure. I will file an enhancement request for that.

    Regards,
    Stephanie


  • 5.  RE: File mapping for onlinelogs

    Posted 03-31-2017 11:26:00 AM
    Hi, Thanks for that Stephanie. Regards, Mouhssine
